Cruise Control Module: Testing and Inspection

Fig. 12 Control Unit Input Test:

1. Disable coded theft protection system as described under Accessories and Optional Equipment / Antitheft and Alarm Systems / Service and Repair.
2. Disable airbag system as outlined under Air Bags and Seat Belts / Air Bags (Supplemental Restraint Systems) / Airbag System Disarming.
3. Disconnect control unit connector.
4. Referring to Fig. 12, perform all tests as shown. Recheck connections between connector and control unit, then reinstall if all tests are satisfactory.
