Home >> BMW >> 2002 >> 325i Sedan (E46) L6-2.5L (M54) >> Repair and Diagnosis >> Diagrams >> Electrical Diagrams >> Body >> Audio, Video and Navigation >> Radio >> Antenna Diversity (Without BMW Reverse RDS (C42)) >> Antenna Amplifier, Diversity >> Antenna Diversity ((Saloon or Coupe) As of 03/01 Without BM on-Board Monitor)

Antenna Diversity ((Saloon or Coupe) As of 03/01 Without BM on-Board Monitor)

Antenna diversity:
