Front Camber Adjustment
^ Tool Required:
- J 29862 Camber Adjustment Tool
- Or Equivalent
Adjust:
1. Loosen both strut to knuckle nuts.
2. Using tool J 29862.
Tighten:
3. Strut to knuckle nuts to 190 Nm (140 ft. lbs.).
4. Remove tool J 29862.
^ Tool Required:
- J 29862 Camber Adjustment Tool
- Or Equivalent
Adjust:
1. Loosen both strut to knuckle nuts.
2. Using tool J 29862.
Tighten:
3. Strut to knuckle nuts to 190 Nm (140 ft. lbs.).
4. Remove tool J 29862.
