Excessive Brake Pulsation

Vehicle Stability Enhancement System Excessive Brake Pulsation

Circuit Description

Steps 1 - 4:

The Vehicle Stability Enhancement System (VSES) is activated by the EBCM calculating the desired yaw rate and comparing it to the actual yaw rate input. The desired yaw rate is calculated from measured steering wheel position, vehicle speed, and lateral acceleration. The difference between the desired yaw rate and actual yaw rate is the yaw rate error, which is a measurement of oversteer or understeer. If the yaw rate error becomes too large, the EBCM will attempt to correct the vehicle's yaw motion by applying differential braking to the left or right front wheel.
