Air Injection Pump Relay: Service and Repair

REMOVAL PROCEDURE




1. Remove the underhood electrical centre.




2. Remove the secondary air pump relay (10).

INSTALLATION PROCEDURE




1. Install the secondary air pump relay (10).




2. Install the underhood electrical center cover.
