Power Liftgate Latch

POWER LIFTGATE LATCH

REMOVAL




1. Remove liftgate trim panels.
2. Disconnect the exterior handle actuator rod (2) from the latch assembly (4).




3. Disconnect the electrical connector (1).
4. Remove the screws (3) and remove the latch (2).

INSTALLATION




1. Position the latch (2) into the liftgate and install the screws (3).
2. Tighten the screws to 11 N.m (95 in. lbs.).




3. Connect the electrical connector (1). Connect the latch actuator rod (2) to the exterior handle (1) and the latch (4).
4. Install the trim panels.
