B1D07

B1D07-MIRROR ADJUST SWITCH INPUT CIRCUIT STUCK

For a complete wiring diagram, refer to the Wiring Information.

- When Monitored:
Whenever the Driver Door Module (DDM) is awake.

- Set Condition:
When the DDM senses the Mirror Adjust switch input for more than 30 seconds.





1. INSPECT DRIVER DOOR SWITCH ASSEMBLY FOR DAMAGE

NOTE: Diagnose and repair all LIN Bus related DTCs before performing this test procedure.

1. Turn the ignition off.
2. Inspect the Driver Door switch assembly for damage.

Is the switch assembly damaged?

Yes

- Replace the Driver Door switch assembly.
- Perform the BODY VERIFICATION TEST. Body Verification Test.

No

- Go To 2

2. INSPECT FOR OBJECT OR SUBSTANCE CAUSING MIRROR ADJUST SWITCH TO STAY OR STICK IN A PUSHED POSITION
1. Inspect the Mirror Adjust switch for anything that would cause it to stay or stick in a pushed position.

Is anything present that would cause the Mirror Adjust switch to stay or stick in a pushed position?

Yes

- Repair as necessary.
- Perform the BODY VERIFICATION TEST. Body Verification Test.

No

- Go To 3

3. TEST FOR INTERMITTENT CONDITION
1. Turn the ignition on.
2. With the scan tool, record and erase DTCs.
3. Press and release either Mirror Select switch.
4. Operate the Mirror Adjust switch in all positions several times and then wait 30 seconds.
5. With the scan tool, read DTCs.

Does the scan tool display: B1D07-MIRROR ADJUST SWITCH INPUT CIRCUIT STUCK?

Yes

- Replace the Driver Door switch assembly.
- Perform the BODY VERIFICATION TEST. Body Verification Test.

No

- The conditions that caused this code to set are not present at this time.
- Perform the BODY VERIFICATION TEST. Body Verification Test.
