Brake Fluid Level Switch - Removal

REMOVAL





1. Disconnect the wire connector (2) from the brake fluid level sensor (3).





2. From the opposite side of the master cylinder reservoir (1) release the sensor locking tabs (2) with a small screw driver.
3. Pull the sensor out of the reservoir (1) from the connector side of the sensor.
