Output Speed Sensor - Installation

INSTALLATION










1. Install the output speed sensor (1)(Figure 1) into the transmission case.
2. Install the bolt to hold the output speed sensor (1) into the transmission case. Tighten the bolt to 12 Nm (105 in.lbs.).
3. Install the wiring connector onto the output speed sensor (1).
4. install the transfer case skid plate (if equipped).
5. Verify the transmission fluid level. Add fluid as necessary.
6. Lower vehicle.
