Servo Control

Fig. 10 Servo Control Location W/Renix System:

1. Remove two retaining nuts (A) securing assembly to inner fender.
2. Remove screws securing plastic cover, then separate base and cover.
3. Disconnect vacuum hose (C) and electrical connector located on inner fender.
4. Reverse procedure to install.
