Center

REMOVAL

NOTE: If only the center register barrels need to be replaced, the cluster finish panel does not need to be removed.

1. Remove the instrument cluster finish panel. Refer to Console.







2. Remove the center registers.
1. Remove the screws.
2. Disengage the eight tabs.
3. Remove the center registers.

INSTALLATION
1. To install, reverse the removal procedure.
