Cruise Control Module: Service and Repair




REMOVAL PROCEDURE

CAUTION: Refer to Battery Disconnect Caution in Cautions and Notices.

1. Disconnect the negative battery cable.
2. Remove the cruise control cable.
3. Disconnect the electrical connector.
4. Remove the cruise control module bolts.
5. Remove the cruise control module.

INSTALLATION PROCEDURE
1. Install the cruise control module.

NOTE: Refer to Fastener Notice in Cautions and Notices

2. Install the cruse control module bolts.

Tighten
Tighten the cruise control module bolts to 12 N.m (106 lb in).

3. Connect the electrical connector.
4. Install the cruise control cable.
5. Connect the negative battery cable.
6. Perform the functional check.
