Heater Assembly

Fig. 20 Removing heater valve cable from heater.:

1. Disconnect battery ground cable.
2. Drain coolant from radiator.
3. Disconnect heater hoses at firewall.
4. Disconnect heater valve cable from heater valve, Fig. 20.
5. Remove heater lower mounting nut.
6. Remove dashboard.
7. Remove heater mounting bolts, then pull heater away from body.
8. Reverse procedure to install.
