Cylinder Head

Cylinder head bolts.
(1) Do not apply engine oil on the the cylinder head bolts.
(2) Using the SST(09221-4A000), tighten the cylinder head bolts and plate washers, in several passes, in the sequence shown.

Tightening torque : 32.4 - 36.3Nm (3.3 - 3.7kgf.m, 23.9 - 26.8lb-ft) + 90 - 95° + 90 - 95°






CAUTION: Always use new cylinder head bolt.

SURFACE VARIATION
