Oil Separator: Service and Repair

REMOVAL
1. Remove the LH cylinder head. For additional information, refer to Engine.







2. Remove the bolts and the oil separator. Discard the gasket.

INSTALLATION
1. To install, reverse the removal procedure.
^ Install a new gasket.
