Auxiliary Water Pump: Service and Repair

REMOVAL
1. Disconnect the battery ground cable.
2. Drain the radiator.







3. Disconnect the connector.







4. Remove the two auxiliary coolant pump to fan shroud bolts.







5. Disconnect the hoses and remove the pump.

INSTALLATION
1. To install, reverse the removal procedure.
- Make sure that the heater hoses are installed in the correct position.
- Lubricate the coolant hoses with MERPOL(R) meeting Ford specification ESE-M99B144-B or plain water only, if needed.
- Check for correct hose installation by verifying DATC system operation.
