Neutral Safety Switch: Testing and Inspection

Fig. 24 Inhibitor Switch Inspection:

1. Disconnect inhibitor switch connector.
2. Connect ohmmeter to switch Fig. 24.
3. Check continuity of terminal. There should be continuity in P and N ranges and there should be no continuity in all other ranges.
