EGR Valve: Service and Repair

EGR Valve Replacement:

Replacement
1. Disconnect the EGR hose.
2. Disconnect the vacuum hose.
3. Disconnect the EGR valve position sensor connector.
4. Remove the EGR valve.
5. Remove the gasket.
6. Install in the reverse order of removal.

Tightening torque: 19-25 Nm (1.7-2.2 ft.lbs.)

NOTE: If nut A is difficult to remove (stuck), first remove the following and then remove the nut together with the EGR pipe from under the vehicle.
1. Transverse member
2. Front pipe
3. Insulator
4. EGR pipe
5. Exhaust manifold.
