Data Link Connector: Description and Operation
Diagnostic Connector:
LOCATION
The Diagnostic Check Connector is located behind the drivers left knee bolster.
PURPOSE
The diagnostic check connector is used to extract fault code information.
LOCATION
The Diagnostic Check Connector is located behind the drivers left knee bolster.
PURPOSE
The diagnostic check connector is used to extract fault code information.
