Installation

Exploded View Of Evaporator Core. Part 1 Of 2.:

Exploded View Of Evaporator Core Legend. Part 2 Of 2.:

Rear Lateral Strut (Mount):

INSTALL OR CONNECT
1. Heater core and heater core retaining straps.
2. Heater core cover.
3. Heater outlet deflector.
4. Right and left sound insulators.
5. Hoist vehicle.
6. Heater hoses to heater core.
7. Drain tube to heater case.
8. Rear lateral transaxle strut (mount) if equipped.
9. Lower vehicle.
10. Fill cooling system and check for leaks.
