Heater Core Case: Service and Repair

Condenser Mounting:

Remove or Disconnect

1. Lower center console (if equipped).
2. Both lower instrument panel lower compartment.
3. Heater outlet case screws.
4. Heater cover screws.
5. Heater cover.

Install or Connect

1. Heater cover.
2. Heater cover screws.

Tighten
^ Screws to 3 N.m (27 lb. in.).

3. Heater outlet case screws.

Tighten
^ Screws to 3 N.m (27 lb. in.).

4. Both lower instrument panel lower compartment.
5. Lower center console (if equipped).
