Service Procedure
Steering Wheel Air Bag Module Replacement(Following applies to both Grand Prix and Montana/Trans Sport except where noted)
For additional information, see the SIR subsection of the Restraints section of the appropriate service manual.
IMPORTANT:
The service procedure contained in this recall is different from the service procedure found in the appropriate service manual. As a result, the labor time allowance has been revised to correspond with this new service procedure. In the near future the service manual and labor time guide will be updated with this new information.
1. Open the instrument panel storage (glove) compartment door. (Grand Prix)
Open the right front door and remove the fuse panel cover. (Montana/Trans Sport)
2. Remove the cover to the right of the compartment to access the fuse panel. (Grand Prix)
3. Remove the 15 amp SIR fuse. See the fuse label on the inside of the removed cover to determine the location of the SIR fuse.
IMPORTANT:
To access the retainers in the next step it will be necessary to rotate or turn the steering wheel.
4. Using a flat-bladed screwdriver or J-44298-A (Driver Air Bag Remover) release the four spring retainers that attach the air bag module to the steering wheel.
5. Remove the air bag from the steering wheel.
6. Disconnect the electrical connector for the horn at the steering wheel.
7. Remove the connector position assurance (CPA) and disconnect the yellow SIR electrical connector at the rear of the air bag module.
8. Connect the yellow SIR electrical connector to the rear of the NEW air bag module and install the CPA.
9. Connect the electrical connector for the horn at the steering wheel.
10. Position and press the air bag module to the steering wheel until the four retainers lock into place.
11. Install the SIR fuse.
12. Install the cover over the fuse panel.
13. Close the instrument panel storage compartment door. (Grand Prix)
14. Turn the ignition switch to the "ON" position and verify that the AIR BAG indicator lamp flashes seven times and goes out. Also verify horn operation.
15. Install the GM Recall Identification Label.
CAUTION
Do NOT deploy the old inflator module. See the "CAUTION" statement.
16. Place the old inflator module in the box that the new module came in using the included packing material. Tape the box shut and mark the outside of the box as follows:
"DO NOT DEPLOY"
"SEE RECALL # 01052A FOR ADDITIONAL INFORMATION"
To arrange for return of inflator modules removed from vehicles involved in this recall ONLY contact Delphi Interiors via telephone at (937)-356-2354. A Delphi representative will make arrangements to pick up and safely dispose of the modules. Removed modules should be stored in an area with limited access.
RECALL IDENTIFICATION LABEL - For US
Place a Recall Identification Label on each vehicle corrected in accordance with the instructions outlined in this Product Recall Bulletin. Each label provides a space to include the recall number and the five (5) digit dealer code of the dealer performing the recall service. This information may be inserted with a typewriter or a ball point pen.
Put the Recall Identification Label on a clean and dry surface of the radiator core support in an area that will be visible to people servicing the vehicle. When installing the Recall Identification Label, be sure to pull the tab to allow adhesion of the clear protective covering. Additional Recall Identification Labels for US dealers can be obtained from Dealer Support Materials by calling 1-866-700-0001 (Monday-Friday, 8:00 a.m. to 5:00 p.m. EST). Ask for Item Number S-1015 when ordering.
RECALL IDENTIFICATION LABEL - For CANADA
Place a Recall Identification Label on each vehicle corrected in accordance with the instructions outlined in this Product Recall Bulletin. Each label provides a space to include the recall number and the five (5) digit dealer code of the dealer performing the recall service. This information may be inserted with a typewriter or a ball point pen.
Put the Recall Identification Label on a clean and dry surface of the radiator core support in an area that will be visible to people servicing the vehicle. Additional Recall Identification Labels for Canadian dealers can be obtained from DGN by calling 1-800-668-5539 (Monday-Friday, 8:00 a.m. to 5:00 p.m. EST). Ask for Item Number GMP 91 when ordering.
