Maintenance: Locations

Engine compartment:




1 Expansion tank - coolant
2 Oil filler cap - engine
3 Dipstick - engine oil
4 Brake fluid reservoir
5 Battery (in trunk)
6 Data plate
7 Radiator/cooling fan
8 Power steering fluid reservoir
9 Air cleaner
10 Washer fluid reservoir
11 Main fuse box
12 Relay/fuse box

WARING: The cooling fan may start or continue to operate (for up to 6 minutes) after the engine has been switched off.
